Ultra High Current, Super compact Servo Drive.-40C to+70C, Vibrations up to 14GRMSDesigned, qualified, verified, manufactured
产品详情
The Gold EAGLE is designed to operate under extreme environmental conditions.
Gold Eagle servo drives operate from a DC power source in current, velocity, position and advanced position modes, in conjunction with a permanent-magnet synchronous brushless motor, DC brush motor, linear motor or voice coil.
The GOLD Eagle has the same control CORE as the Gold Line of servo drives, the Gold Eagle is fully programmable with Elmo’s motion control language.
Mating Power Supply ELP-30.
Gold Eagle Highlights:
Gold Line core motion control technology
Advanced and extremely fast vector control algorithm (current loop bandwidth: 4 kHz)
Highly efficient, high bandwidth performance
Multiple communication options: CAT, CANopen, RS232, RS422 USB, Ethernet
Supports a wide variety of feedback: Incremental, Encoder, Resolver, Digital Halls, Analog Halls, Analog 1V ptp (Sin/Cos), Absolute Serial Encoders, Tachometer, Potentiometer
Advanced filtering and gain scheduling options for enhanced dynamic performance
Easily optimized set up and tuned using Elmo Application Studio (EAS) software tools
Supports PLC Source, PLC Sink and TTL I/O types
Complies to the most severe Safety, EMC and environmental standards.
| Feature | Units | 70/60 | 50/100 | 100/100 | R150/100 | 35/200 | R60/200 |
|
Minimum supply voltage |
VDC |
14 |
46 | ||||
|
Nominal supply voltage |
VDC |
50 |
85 |
170 | |||
|
Maximum supply voltage |
VDC |
59 |
95 |
195 | |||
|
Maximum continuous power output |
W |
3400 |
4000 |
8000 |
12000 |
5600 |
9600 |
|
Efficiency at rated power (at nominal conditions) |
% |
> 99 | |||||
|
Max output voltage |
97% of DC bus voltage at f=22 kHz | ||||||
|
VL Logic supply input voltage |
VDC
|
14 to 72 | |||||
|
VL Logic supply input power |
VA |
≤ 4 VA without external loading of 5V (Encoders) ≤ 6 VA with full external loading of 5V (2 encoders) |
|||||
|
Amplitude sinusoidal/DC continuous curren |
A |
70 |
50 |
100 |
150 |
35 |
60 |
|
Sinusoidal continuous RMS current limit (Ic) |
A |
50 |
35 |
70 |
106 |
25 |
42 |
|
Peak current limit |
A |
2 x Ic |
2 x Ic |
2 x Ic |
No Peak |
2 x Ic |
No Peak |
