Gold Double BeeThe World’s Toughest, Most Advanced and Powerful Miniature Servo Drive.Provides over 10,000 of Qualitative Wat
产品详情
Gold Double Bee Highlights:
High power density, over 10000 of “Qualitative” Watts
Ultra high current – up to 160A/80V, 140A/100V
Record-setting weight of only 18-22 grams (less than 1 ounce)
Ultra Small, Ultra Efficient, designed to be mounted on a PCB
Advanced networking by EtherCAT Or CANOpen
Wide Operating ranges:
“80VDC”,11VDC- 75VDC
“100VDC”, 11VDC- 95VDC
“200VDC”, 20VDC- 195VDC
Supports any feedback sensor in single, dual and gantry loop configurations
Incorporates Proprietary “Fast and Soft Switching Technology” resulting in >99% efficiency yet negligible EMI
Feature | Units | D160/80 | D140/100 | D40/200 |
|---|---|---|---|---|
Minimum supply voltage | VDC | 11 | 11 | 20 |
Nominal supply voltage | VDC | 65 | 85 | 170 |
Maximum supply voltage | VDC | 75 | 95 | 195 |
Maximum continuous Electrical power output | kW | 10 | 11 | 7 |
Efficiency at rated power (at nominal conditions) | % | > 99 | ||
Maximum output voltage | Up to 96% of DC bus voltage | |||
Amplitude sinusoidal/DC continuous current | A | 160 | 140 | 40 |
Not for DC Motor | A | 113 | 99 | 28 |
For DC Motor only | A | 100 | 40 | |
Current limit | A | Max Output current is guaranteed for THeat-Sink <85°C | ||
